RXG interface plug-in relays

RXG relays are interface plug-in relays with Faston pins for better reliability and robust installation. They are used in PLC applications.

Benefits

Large choice of number of contacts (up to 2)
Easy installation & maintenance:
* Plug in type with standard pin arrangement (with socket)
* Energy Management
* Asset Management
Input and output current and voltage adaptation

Applications

Industrial machines
Machines and building or medical equipement
Packaging machines
Textile machines
HVAC
Simple hard-wired logic control system cycles
Extra feature for industrial PLCs

Index

1. Interface plug-in relays
with lockable test button

2. Interface plug-in relays
with lockable test button and LED indicator

3. Interface plug-in relays
with LED indicator

4. Interface plug-in relays
with transparent cover

5. Surge protection modules for RXG sockets

6. Accessories for RXG relays and RZM sockets

7. Additional documentation

1. Interface plug-in relays with lockable test button

(back to index)

		AC coil voltage (see corresponding sockets by swiping right)					DC coil voltage (see corresponding sockets by swiping right)						Recommended sockets
Contact	Rated current	24Vac	48Vac	120Vac	220Vac	230Vac	6Vdc	12Vdc	24Vdc	48Vdc	60Vdc	110Vdc	Sockets with separate contact terminals, screw connector connection, and built-in clamp
1 C/O SPDT	IEC: 250Vac / 30Vdc: 10A UL: 250Vac / 30Vdc: 10A	RXG11B7	RXG11E7	RXG11F7	RXG11M7	RXG11P7	RXG11RD	RXG11JD	RXG11BD	RXG11ED	RXG11ND	RXG11FD	RGZE1S35M
2 C/O DPDT	IEC: 250Vac / 30Vdc: 5A UL: 250Vac / 30Vdc: 5A	RXG21B7	RXG21E7	RXG21F7	RXG21M7	RXG21P7	RXG21RD	RXG21JD	RXG21BD	RXG21ED	RXG21ND	RXG21FD	RGZE1S48M

2. Interface plug-in relays with lockable test button and LED indicator

(back to index)

		AC coil voltage (see corresponding sockets by swiping right)					DC coil voltage (see corresponding sockets by swiping right)						Recommended sockets
Contact	Rated current	24Vac	48Vac	120Vac	220Vac	230Vac	6Vdc	12Vdc	24Vdc	48Vdc	60Vdc	110Vdc	Sockets with separate contact terminals, screw connector connection, and built-in clamp
1 C/O SPDT	IEC: 250Vac / 30Vdc: 10A UL: 250Vac / 30Vdc: 10A	RXG12B7	RXG12E7	RXG12F7	RXG12M7	RXG12P7	RXG12RD	RXG12JD	RXG12BD	RXG12ED	RXG12ND	RXG12FD	RGZE1S35M
2 C/O DPDT	IEC: 250Vac / 30Vdc: 5A UL: 250Vac / 30Vdc: 5A	RXG22B7	RXG22E7	RXG22F7	RXG22M7	RXG22P7	RXG22RD	RXG22JD	RXG22BD	RXG22ED	RXG22ND	RXG22FD	RGZE1S48M

3. Interface plug-in relays with LED indicator

(back to index)

		AC coil voltage (see corresponding sockets by swiping right)					DC coil voltage (see corresponding sockets by swiping right)						Recommended sockets
Contact	Rated current	24Vac	48Vac	120Vac	220Vac	230Vac	6Vdc	12Vdc	24Vdc	48Vdc	60Vdc	110Vdc	Sockets with separate contact terminals, screw connector connection, and built-in clamp
1 C/O SPDT	IEC: 250Vac / 30Vdc: 10A UL: 250Vac / 30Vdc: 10A	RXG13B7	RXG13E7	RXG13F7	RXG13M7	RXG13P7	RXG13RD	RXG13JD	RXG13BD	RXG13ED	RXG13ND	RXG13FD	RGZE1S35M
2 C/O DPDT	IEC: 250Vac / 30Vdc: 5A UL: 250Vac / 30Vdc: 5A	RXG23B7	RXG23E7	RXG23F7	RXG23M7	RXG23P7	RXG23RD	RXG23JD	RXG23BD	RXG23ED	RXG23ND	RXG23FD	RGZE1S48M

4. Interface plug-in relays with transparent cover

(back to index)

		AC coil voltage (see corresponding sockets by swiping right)					DC coil voltage (see corresponding sockets by swiping right)						Recommended sockets
Contact	Rated current	24Vac	48Vac	120Vac	220Vac	230Vac	6Vdc	12Vdc	24Vdc	48Vdc	60Vdc	110Vdc	Sockets with separate contact terminals, screw connector connection, and built-in clamp
1 C/O SPDT	IEC: 250Vac / 30Vdc: 10A UL: 250Vac / 30Vdc: 10A	RXG15B7	RXG15E7	RXG15F7	RXG15M7	RXG15P7	RXG15RD	RXG15JD	RXG15BD	RXG15ED	RXG15ND	RXG15FD	RGZE1S35M
2 C/O DPDT	IEC: 250Vac / 30Vdc: 5A UL: 250Vac / 30Vdc: 5A	RXG25B7	RXG25E7	RXG25F7	RXG25M7	RXG25P7	RXG25RD	RXG25JD	RXG25BD	RXG25ED	RXG25ND	RXG25FD	RGZE1S48M

5. Surge protection modules for RXG sockets

(back to index)

		Compatible with coils
	6-230V	24-60V	110-240V	6-24V	110-230V
Diode (DC only)	RZM040W	-	-	-	-
RC circuit (AC only)	-	RZM041BN7	RZM041FU7	-	-
Diode + green LED (DC only)	-	RZM031BN	-	RZM031RB	RZM031FPD
Varistor + green LED (AC/DC)	-	RZM021BN	-	RZM021RB	RZM021FP

6.Accessories for RXG relays and RZM sockets

(back to index)

	Accessories
Product	RGZR215	RSZL300	RGZL520
Description	Plastic maintaining clamp	Legend	Legend
For use with	RGZE1S⬤⬤⬤	RGZE1S⬤⬤⬤	RGZE1S⬤⬤⬤

7. Documentation

(back to index)

Zelio Relays Catalogue
