A&D precision weighing scales and balances

A&D Company, Limited, Japan’s top manufacturer of electronic weighing instruments, is particularly proud of the unmatched width of our product portfolio, with innovations always aimed at providing users with high practical utility and high value for the price. The fact is that no matter what industry you are in, whatever use you have in mind, or whatever solution you are looking for, you will likely find a product that precisely fits your requirements, within your budget!

Index

Section 1. Weighing balances

Section 2. Weighing scales

2.1. Dust-proof and waterproof scales

2.2. Platform scales

2.3. Counting scales

FC-Si series

FC-i series

HC-i series

2.4. Compact scales

HT-120 series

1.1 Analytical balances

(back to index)

Product series	BM series						GH series					GR series				HR-i series
Benefits	Instant and smooth static elimination using a built-in fanless ionizer to ensure stable weighing Large working space for better operability and a wider range of applications Interlockable slide doors allowing efficient operation with both hands						Semi-micro, 0.01 mg resolution up to 101 g (GH-252) Adjustable (manual or automatic) response characteristics to help cope with the effect of drafts and vibrations Automatic self calibration to maintain accuracy under temperature changes					Semi-micro, 0.01 mg resolution up to 42 g (GR-202) Handy lever on the front to open either side of the weighing chamber for quick and efficient access Small footprint of 249 mm by 330 mm to save space				Semi-micro, 0.01 mg resolution up to 51 g (HR-202i) Adjustable response characteristics to help cope with the effect of drafts and vibrations Anti-static glass breeze break with a thin evaporated metal coating
Weighing capacity	22g	5.1g or 22g	250g	220g	320g	520g	250 x 0.0001g / 250,000 x 0.1mg or 101 x 0.00001g / 101,000 x 0.01mg	220 x 0.0001g / 220,000 x 0.1mg or 51 x 0.00001g / 51,000 x 0.01mg	320 x 0.0001g 320,000 x 0.1mg	220 x 0.0001g 220,000 x 0.1mg	120 x 0.0001g 120,000 x 0.1mg	210 x 0.0001g / 210,000 x 0.1mg or 42 x 0.00001g / 42,000 x 0.01mg	310 x 0.0001g 310,000 x 0.1mg	210 x 0.0001g 210,000 x 0.1mg	120 x 0.0001g 120,000 x 0.1mg	220 x 0.0001g / 220,000 x 0.1mg or 51 x 0.00001g / 51,000 x 0.01mg	320 x 0.0001g 320,000 x 0.1mg
Pan size	Ø25mm		Ø90mm				Ø90mm		Ø90mm			Ø85mm				Ø90mm	Ø90mm
Product code	BM-20	BM-22	BM-252	BM-200	BM-300	BM-500	GH-252	GH-202	GH-120	GH-200	GH-300	GR-202	GR-302	GR-200	GR-120	HR-202i	HR-300i
Minimum weighing value	0.001mg or 0.01mg	0.01mg	0.001mg	0.1mg			0.1mg or 0.01mg		0.1mg			0.1mg or 0.01mg	0.1mg			0.1mg or 0.01mg	0.1mg
Repeatability (standard deviation)	0.0025mg (1g)	0.004mg (1g) or 0.01mg	0.03mg (100g)	0.1mg	0.2mg		0.1mg or 0.03mg	0.1mg or 0.02mg	0.2mg	0.1mg		0.0001g or 0.00002g	0.0002g	0.0001g		0.1mg or 0.02mg	0.2mg
Linearity	±0.010 mg	±0.010 mg or ±0.02 mg	±0.10 mg	±0.2 mg	±0.3 mg	±0.5 mg	±0.2mg or ±0.10mg	±0.2mg or ±0.03mg	±0.2mg		±0.3mg	±0.0002g or ±0.00003g	±0.0003g	±0.0002g		±0.2mg or ±0.03mg	±0.3mg
Stabilization time	10s	10s or 8s	8s	3.5s			3.5s (0.1mg) or 8s (0.01mg)		3.5s			3.5s or 8s	3.5s			3.5s (0.1mg) or 8s (0.01mg)	3.5s
Display type and mode	Vacuum Fluorescent display (VFD) (g, mg, oz, ozt, ct, mom, dwt, GN, tael, tola, PC (counting mode), % (percent mode), Specific gravity)						LCD display (Decimal Ounce (oz), Troy Ounce (ozt), Pennyweight (dwt), Carat (ct), Momme (mom), Grain Unit (GN), Tola (t), Tael (TL))					LCD display (g, mg, pcs, %, oz, ozt, ct, mom, dwt, GN, tl, t (tola), m (messghal))				LCD display (Decimal Ounce (oz), Troy Ounce (ozt), Pennyweight (dwt), Carat (ct), Momme (mom), Grain Unit (GN), Tola (t), Tael (TL))
Power supply	With AC power adapter (included)						With AC power adapter (included)					With AC power adapter (included) or optional rechargeable battery				With AC power adapter (included)
Display refresh rate	5 or 10 times / s						5 or 10 times / s					5 or 10 times / s				5 or 10 times / s
Communication capability	Built-in RS-232C + USB interface Optional Ethernet with BM-08						Built-in RS-232C Optional Ethernet with GH-08 Optional USB interface with GH-02					Optional Ethernet with AD-8526				Built-in RS-232C Optional Ethernet with GH-08 Optional USB interface with GH-02

1.2. Precision balances for standard and industrial applications: FZ-i/FX-i Series, FZ-iWP/FX-iWP Series, GX-A/GF-A Series, GX/GF Series, GX-K/GF-K Series, GP Series

(back to index)

Product series		FZ-i series								FX-i series								FZ-iWP series						FX-iWP series						GX-A series													GF-A series															GX-K series							GF-K series							GP series									GP-S series
Benefits		High-speed weighing with 1-second stabilization Compact foot print: 198 mm × 294 mm (smaller than an A4 sheet of paper) Protection mechanism against vertical and transverse overloading								High-speed weighing with 1-second stabilization Compact foot print: 198 mm × 294 mm (smaller than an A4 sheet of paper) Protection mechanism against vertical and transverse overloading								IP65 compliant, dust and waterproof High-speed weighing with 1-second stabilization Compact foot print: 198 mm × 294 mm (smaller than an A4 sheet of paper)						IP65 compliant, dust and waterproof High-speed weighing with 1-second stabilization Compact foot print: 198 mm × 294 mm (smaller than an A4 sheet of paper)						Impact shock detection (ISD) that visualizes what degree of Impact shock is detrimental to the balance and allows users to take preventive measures as necessary Flow rate display (FRD) that makes calculating and recording Flow rates easier and more accurate Auto precision assessment (APA) and minimum weight calculation using electronically controlled load (ECL)													Impact shock detection (ISD) that visualizes what degree of Impact shock is detrimental to the balance and allows users to take preventive measures as necessary Flow rate display (FRD) that makes calculating and recording Flow rates easier and more accurate Auto precision assessment (APA) and minimum weight calculation using electronically controlled load (ECL)															IP65 compliant, dust and waterproof Adjustable response characteristics to help cope with the effect of drafts and vibrations (manual or automatic) Automatic self calibration to maintain accuracy under temperature changes							IP65 compliant, dust and waterproof Adjustable response characteristics to help cope with the effect of drafts and vibrations (manual)							IP65 compliant, dust and waterproof Adjustable swing arm display Adjustable (manual or automatic) response characteristics to help cope with the effect of drafts and vibrations									IP65 compliant, dust and waterproof Detached display stand. Adjustable (manual or automatic) response characteristics to help cope with the effect of drafts and vibrations
Weighing capacity		122g	220g	320g	520g	1220g	2200g	3200g	5200g	122g	220g	320g	520g	1220g	2200g	3200g	5200g	122g	220g	320g	1,220g	2,200g	3,200g	122g	220g	320g	1,220g	2,200g	3,200g	220g	320g	420g	620g	1100g	1620g	2200g	3200g	4200g	6200g	10,200g	6200g	10,200g	120g	220g	320g	420g	620g	1100g	1620g	1200g	2200g	3200g	4200g	6200g	10,200g	6200g	10,200g	8.1kg	2.1kg 8.1kg	10.1kg	12kg	21kg	31kg	6.1kg 31kg	8.1kg	2.1kg 8.1kg	10.1kg	12kg	21kg	31kg	6.1kg 31kg	12kg	21kg	31kg	6.1kg 31kg	41kg	61kg	61kg	101kg	61kg 101kg	31kg	6.1kg 31kg	61kg	61kg	101kg
Pan size		Ø130mm				Ø150mm				Ø130mm				Ø150mm				Ø130mm						Ø150mm						270 x 210mm													128 x 128mm							165 x 165mm								270 x 210mm							270 x 210mm							344 x 384mm							346 x 386mm		344 x 384mm				346 x 386mm
Product		FZ-120i	FZ-200i	FZ-300i	FZ-500i	FZ-1200i	FZ-2000i	FZ-3000i	FZ-5000i	FX-120i	FX-200i	FX-300i	FX-500i	FX-1200i	FX-2000i	FX-3000i	FX-5000i	FZ-120iWP	FZ-200iWP	FZ-300iWP	FZ-1200iWP	FZ-2000iWP	FZ-3000iWP	FX-120iWP	FX-200iWP	FX-300iWP	FX-1200iWP	FX-2000iWP	FX-3000iWP	GX-203A	GX-303A	GX-403A	GX-603A	GX-1003A	GX-1603A	GX-2002A	GX-3002A	GX-4002A	GX-6002A	GX-10002A	GX-6001A	GX-10001A	GF-123A	GF-203A	GF-303A	GF-403A	GF-603A	GF-1003A	GF-1603A	GF-1202A	GF-2002A	GF-3002A	GF-4002A	GF-6002A	GF-10002A	GF-6001A	GF-10001A	GX-8K	GX-8K2	GX-10K	GX-12K	GX-20K	GX-30K	GX-32K	GF-8K	GF-8K2	GF-10K	GF-12K	GF-20K	GF-30K	GF-32K	GP-12K	GP-20K	GP-30K	GP-32K	GP-40K	GP-60K	GP-61K	GP-100K	GP-102K	GP-30KS	GP-32KS	GP-60KS	GP-61KS	GP-100KS
Minimum weighing value		0.001g				0.01g				0.001g				0.01g				0.001g			0.01g			0.001g			0.01g			0.001g						0.01g					0.1g		0.001g							0.01g						0.1g		0.01g	0.01g or 0.1g	0.01g	0.1g			0.01g or 0.1g	0.01g	0.01g or 0.1g	0.01g	0.1g			0.01g or 0.1g	-									-
Repeatability (standard deviation)		0.001g								0.01g								0.001g						0.01g						0.001g					0.001g (≤1000g) / 0.002g (>1000g)	0.01g				0.00001kg (≤5kg) / 0.00002kg (>5kg)	0.1g		0.001g						0.001g (≤1000g) / 0.002g (>1000g)	0.01g					0.00001kg (≤5kg) / 0.00002kg (>5kg)	0.1g		0.01g	0.01g (≤2.1kg) / 0.05g (>2.1kg)	0.01g	0.1g			0.1g (≤6.1kg) / 0.5g (>6.1kg)	0.01g	0.01g (≤2.1kg) / 0.05g (>2.1kg)	0.01g	0.1g			0.1g (≤6.1kg) / 0.5g (>6.1kg)	0.1g			0.0001kg (≤6.1kg) / 0.0005kg (>6.1kg)	0.5g	0.7g	0.2g	1g	2g (≤61kg) / 10g (>61kg)	0.1g	0.0001kg (≤6.1kg) / 0.0005kg (>6.1kg)	0.7g	0.2g	1g
Linearity		±0.002g								±0.02g								±0.002g						±0.02g						±0.002g				±0.003g		±0.02g			±0.03g		±0.1g		±0.002g					±0.003g		±0.02g				±0.03g		±0.1g		±0.03g	±0.02g (≤2.1kg) / ±1g (>2.1kg)	±0.03g	±0.2g			±0.2g (≤6.1kg) / ±1g (>6.1kg)	±0.03g	±0.02g (≤2.1kg) / ±1g (>2.1kg)	±0.03g	±0.2g			±0.2g (≤6.1kg) / ±1g (>6.1kg)	±0.2g			±0.0002kg (≤6.1kg) / ±0.001kg (>6.1kg)	±1g		±0.5g	±2g	±0.002kg (≤61kg) / ±0.01kg (>61kg)	±0.2g	±0.0002kg (≤6.1kg) / ±0.001kg (>6.1kg)	±1g	±0.5g	±2g
Stabilization time (approx.)		1s								1s								1s												0.8 / 1s					0.8 / 1.5s	0.8 / 1s				0.8 / 1.5s	0.8 / 1s		0.8 / 1s						0.8 / 1.5s	0.8 / 1s					0.8 / 1.5s	0.8 / 1s		1.5s														1.5s									1.5s
Display type and mode		Vacuum Fluorescent display (VFD)								Vacuum Fluorescent display (VFD)								Vacuum Fluorescent display (VFD) (g)												LCD display (with backlight)													LCD display (with backlight)															Vacuum Fluorescent Display (VFD) (g, kg)														Vacuum Fluorescent display (VFD)									Vacuum Fluorescent display (VFD)
Power supply		With AC power adapter (included) or optional rechargeable battery FXi-09								With AC power adapter (included) or optional rechargeable battery FXi-09								With AC power adapter (included) or optional rechargeable battery FXi-09												With AC power adapter (included) or optional rechargeable battery AD-1682													With AC power adapter (included) or optional rechargeable battery AD-1682															With AC power adapter (included) or optional rechargeable battery AD-1682														With AC power adapter (included)									With AC power adapter (included)
Display refresh rate		5 or 10 or 20 times / s								5 or 10 or 20 times / s								5 or 10 or 20 times / s												5 or 10 or 20 times / s													5 or 10 or 20 times / s															5 or 10 times / s														5 or 10 times / s									5 or 10 times / s
I/O	Communication capability	Built-in RS-232C Optional USB interface with FXi-02 Optional Ethernet with FXi-08								Built-in RS-232C								Optional Ethernet with FXi-08 Optional USB with FXi-02												Built-in RS-232C and USB interfaces Optional Ethernet with AD-8526 Optional secondary RS-232C interface with GXA-03													Built-in RS-232C and USB interfaces Optional Ethernet with AD-8526 Optional secondary RS-232C interface with GXA-03															Built-in RS-232C Optional Ethernet with AD-8526 Optional secondary RS-232C interface with GX-04K														Built-in RS-232C									Built-in RS-232C
I/O	Outputs	-								-								-												Optional comparator relay output with GXA-04													Optional comparator relay output with GXA-04															Optional comparator relay output (with buzzer) with GX-04K														Optional comparator relay output + buzzer + analog current loop (4-20mA) with GP-04									Optional comparator relay output + buzzer + analog current loop (4-20mA) with GP-04

1.3. Compact balances: EK-EP Series, EJ Series, EK-i/EW-i Series

(back to index)

Product series	EK-EP series			EJ series				EK-i series													EW-i series
Benefits	Intrinsically safe: for use in potentially explosive atmospheres Compact, lightweight and extremely affordable while providing excellent explosion protection Battery operation (approx. 250 hours) for high portability, requiring no power supply from a safe area via a safety barrier Easy-to-read LCD display with backlight (16 mm character height)			High resolution (1/120,000 - 1/310,000) load cell as the weight sensor Breeze break with anti-static coating to ensure high precision and stability (for the EJ-123/303) Adjustable response characteristics depending on the degree of drafts and vibrations at the location				Hygienic and chemically resistant stainless steel (SUS304) weighing pan Adjustable response characteristics to help cope with the effect of drafts and vibrations Multiple weighing units: g, oz, lb, ozt, ct, mom, dwt, grain (either tael, tola or N can be added upon request)													Hygienic and chemically resistant stainless steel (SUS304) weighing pan Adjustable response characteristics to help cope with the effect of drafts and vibrations Multiple weighing units: g, oz, lb, ozt, ct, mom, dwt, grain (either tael, tola or N can be added upon request)
Weighing capacity	300g	3000g	12kg	120g	310g	1200g	3100g	120 x 0.01g	200 x 0.01g	300 x 0.01g	400 x 0.01g	600 x 0.01g	600 x 0.1g	4,000 x 0.1g	6,000 x 0.1g	1200 x 0.1g	2,000 x 0.1g	3,000 x 0.1g	6,000 x 1g	12,000 x 1g	30 x 0.01g 60 x 0.02g 150 x 0.05g	300 x 0.1g 600 x 0.2g 1500 x 0.5g	3000 x 1g 6000 x 2g 12000 x 5g
Pan size	Ø110mm	170x133mm		Ø110mm		140x127mm		Ø110mm					133x170mm								Ø110mm	133x170mm
Product	EK-300EP	EK-3000EP	EK-12KEP	EJ-123	EJ-303	EJ-1202	EJ-3002	EK-120i	EK-200i	EK-300i	EK-410i	EK-610i	EK-600i	EK-1200i	EK-2000i	EK-3000i	EK-4100i	EK-6100i	EK-6000i	EK-12Ki	EW-150i	EW-1500i	EW-12Ki
Minimum weighing value	0.01g	0.1g	1g	0.001g		0.01g		0.01g					0.1g						1g
Repeatability (standard deviation)	0.01g	0.1g	1g	0.003g		0.03g		0.01g			0.01g		0.1g						1g		(≤30g) 0.01g (30-60g) 0.02g (>60g) 0.05g	(≤300g) 0.1g (300-600g) 0.2g (>600g) 0.5g	(≤3kg) 0.001kg (3-6kg) 0.002kg (>6kg) 0.005kg
Linearity	±0.02g	±0.02g	±1g	±0.003g		±0.03g		±0.01g		±0.02g			±0.1g			±0.2g			±1g		(≤30g) ±0.01g (30-60g) ±0.02g (>60g) ±0.05g	(≤300g) ±0.1g (300-600g) ±0.2g (>600g) ±0.5g	(≤3kg) ±0.001kg (3-6kg) ±0.002kg (>6kg) ±0.005kg
Display type and mode	LCD display (with backlight) (g)			LCD display (with backlight) (g)				LCD display (with backlight) (Decimal Ounce(av)(oz), Decimal Pound(av)(lb), Troy Ounce(ozt), Pennyweight(dwt), Carat(ct), Momme(mom), Grain Unit(GN), Tael(H.K General)(tl))													LCD display (with backlight)
Power supply	4 x AA batteries			With AC power adapter (included) or 4 x AA batteries				With AC power adapter (included) or NiMH pack EKW-09i													With AC power adapter (included) or NiMH pack EKW-09i
Display refresh rate	-			10 times / s				10 times / s													10 times / s

1.4. Production weighing systems: AD-4212D Series, AD-4212C Series, AD-4212B Series, AD-4212A Series

(back to index)

Product series		AD-4212D series				AD-4212C series						AD-4212A series				AD-4212B series
Benefits		Minimum weighing value from 1 µg EM-DLC technology for direct connection to a PC or PLC Compact size and resistance to vacuum state ideal for use in a glove box				Fast stabilization (0.5 sec. at 1 mg and 1.3 sec. at 0.1 mg) Slim size (59 mm width) for installation in narrow spaces Direct digital data output to a panel computer, PLC, or PC via RS-232C						Fast stabilization (0.8 sec. at 1 mg, 1.1 sec. at 0.1 mg) Slim separate weighing sensor unit (80 mm width) for compact setups Protection mechanism against vertical and transverse overloading due to actuator malfunctions, etc.				Minimum weighing value from 1 μg Fast stabilization of 4.0 seconds for 0.01 mg resolution Suitable for installation and weighing in vacuum chambers
Weighing capacity		32 g	5.1 g or 32 g	320 g	320 g	51g or 320g	320g	620g	510g or 3200g	3200g	6200g	110g	210g	610g	1100g	21g	31g or 110g	110g	210g	310g
Minimum weighing value		0.001mg	0.001mg / 0.01mg	0.01mg	0.1mg	0.0001g (0.1mg) or 0.001g (1mg)	0.001g (1mg)		0.001g or 0.01g	0.01g		0.001g (0.1mg)	0.001g (1mg)			0.001mg	0.01mg or 0.1mg	0.01mg	0.1mg
Product		AD-4212D-33	AD-4212D-32	AD-4212D-302	AD-4212D-301	AD-4212C-301	AD-4212C-300	AD-4212C-600	AD-4212C-3100	AD-4212C-3000	AD-4212C-6000	AD-4212A-100	AD-4212A-200	AD-4212A-600	AD-4212A-1000	AD-4212B-23	AD-4212B-101	AD-4212B-102	AD-4212B-201	AD-4212B-301
Repeatability (standard deviation)		0.002mg	0.004mg / 0.02mg	0.02mg	0.07mg	0.0002g or 0.001g	0.001g	0.001g	0.002g / 0.01g	0.01g		0.00015g (0.15mg)	0.001g (0.1mg)			0-10g: 0.003 mg 10-21g: 0.004 mg	0.05mg or 0.1mg	0-30g : 0.02mg 30-100g : 0.04mg	0.1mg	0.2mg
Linearity		±0.02mg	±0.03mg	±0.15mg	±0.25mg	±0.002g (±2mg)	±0.002g (±2mg)	±0.005g (±5mg)	±0.02g	±0.02g	±0.04g	±0.0003g (±0.3mg)	±0.002g (±2mg)	±0.003g (±3mg)		±0.01mg	±0.05mg / ±0.2mg	±0.1mg	±0.2mg	±0.3mg
Stabilization time		7s		7s	3s	0-51g: 1.3s 51-320g: 1.0s	0-30g: 0.5s 30-320g: 1.0s	0-30g: 0.5s 30-620g: 1.0s	0-510g: 1.3s 510-3200g: 1.0s	0-300g: 0.5s 300-3200g: 1.0s	0-300g: 0.5s 300-6200g: 1.0s	0-30g: 1.1s 30-110g: 1.3s	0-30g: 0.8s 30-210g: 1sec	0-30g: 0.9s 30-610g: 1.1s	0-30g: 0.9s 30-1100g: 1.1s	12s	4.0s / 2.5s	4.0s	2.5s	2.5s
Display type and mode		AD-1691 display (included)				External display (purchased separately)						VFD display (g)				VFD display (g, mg, oz, ozt, ct, mom, dwt, GN, tael, tola, PC (counting mode), Pct (percent mode))
Display type and mode		5 or 10 times / s				10 to 50 times / s						5 or 10 times / s				5 or 10 times / s
I/O	Communication capability	Built-in RS-232C Optional CC-Link with AD-8923-CC Optional Ethernet with AD-8526										Built-in RS-232C Optional Ethernet with AD4212A-08
	Comparator output	-										Yes (relay contact output)				Yes (relay contact output, 3 or 5 levels, with buzzer)
	External input	-										Re-zero, print				Re-zero, print

2.1. Dust-proof and waterproof scales: SW series, SC series, SE series, FS-i series, HV-WP/HW-WP series, SJ-WP series, SK-WP series, HL-WP series

(back to index)

Product series		SW series (IP69K super washdown, all-stainless steel construction)								SC series (IP68 washdown / submersible)					SE series (IP68 washdown / submersible)					FS-i series (IP65 with comparator Red/Yellow/Green lights)			HV-WP Titan series (IP65)			HW-WP Titan series (IP65)				SJ-WP series				SK-WP Titan series						HL-WP Titan Mini series
Benefits		Ultimate protection against the effects of condensation as well as water Streamlined construction for easy cleaning of food-processing residues stainless steel weighing pan, frame and load cell								Submersible IP68 compliant and fit for extremely wet work environments Washdown construction for easy cleaning 5,000 hours of continuous operation with 6 D alkaline batteries					Submersible IP68 compliant and fit for extremely wet work environments Washdown construction for easy cleaning 5,000 hours of continuous operation with 6 D alkaline batteries					Ultra high-speed weighing with 0.5-second stabilization Distinct tricolor LEDs for fast and error-free comparator judgment Take-away checkweighing using the auto-tare function			Washable and hygienic stainless steel (SUS304) display unit and weighing pan Triple weighing ranges Simple batch function and full/dribble batch function			Washable and hygienic stainless steel (SUS304) display unit and weighing pan 1/10,000 high resolution Simple batch function and full/dribble batch function				Submersible, IP67 dust and waterproof for thorough washing Externally mounted load cell to realize fast stabilization (max. 0.5 seconds) 5000 hours of continuous operation with 6 D alkaline batteries (LED and backlight off)				Washable and hygienic stainless steel (SUS304) construction Long battery life of approx. 1200 hours (with alkaline batteries) Large and wide-angle LCD display with 25 mm character height						Washable and hygienic stainless steel (SUS304) construction Small footprint Battery life of approx. 200 hours (with alkaline batteries)
Weighing capacity		6kg 13lb	15kg 33lb	15kg 33lb	30kg 66lb	60kg 130lb	150kg 330lb	60kg 130lb	150kg 330lb	5g...30kg	10g...60kg	20g...150kg	10g...60kg	20g...150kg	30kg	60kg	150kg	60kg	150kg	6kg	15kg	30kg	3kg / 6kg / 15kg 6lb / 15lb / 30lb	15kg / 30kg / 60kg 30lb / 60lb / 150lb	60kg / 150kg / 220kg 150lb / 300lb / 500lb	10kg 20lb	60kg 150lb	100kg 200lb	220kg 500lb	3kg	6kg	15kg	30kg	1kg	2kg	5kg	5kg	10kg	20kg	300g	1000g	3000g	3000g
Pan size		250 x 250mm pan		300 x 380mm pan				390 x 530mm pan		300 x 380mm pan			390 x 530mm pan		300 x 380mm pan			390 x 530mm pan		250 x 250mm pan		380 x 300mm pan	250 × 250mm pan	330 × 424mm pan	390 × 530mm pan	250 × 250mm pan	330 x 424mm pan	390 x 530mm pan		232 x 192mm pan				232 x 192mm pan						128 x 128mm pan		174 x 137mm pan
Product		SW-6KS	SW-15KS	SW-15KM	SW-30KM	SW-60KM	SW-150KM	SW-60KL	SW-150KL	SC-30KAM	SC-60KAM	SC-150KAM	SC-60KAL	SC-150KAL	SE-30KAM	SE-60KAM	SE-150KAM	SE-60KAL	SE-150KAL	FS-6Ki	FS-15Ki	FS-30Ki	HV-15KV-WP	HV-60KV-WP	HV-200KV-WP	HW-10KV-WP	HW-60KV-WP	HW-100KV-WP	HW-200KV-WP	SJ-3000WP	SJ-6000WP	SJ-15KWP	SJ-30KWP	SK-1000WP	SK-2000WP	SK-5000WP	SK-5001WP	SK-10KWP	SK-20KWP	HL-300WP	HL-1000WP	HL-3000WP	HL-3000LWP
Minimum weighing value		0.5g 0.001lb	1g 0.002lb	1g 0.002lb	2g 0.005lb	5g 0.01lb	10g 0.02lb	5g 0.01lb	10g 0.02lb	0.0005 kg	0.001 kg	0.002 kg	0.001 kg	0.002 kg	0.0005 kg	0.001 kg	0.002 kg	0.001 kg	0.002 kg	0.5g	1g	2g	-			-				0.1g	0.2g	0.5g	1g	0.5g	1g	2g	1g	5g	20g	0.1g	0.5g	1g	1g
Repeatability (standard deviation)		0.001kg	0.002kg	0.002kg	0.005kg	0.01kg	0.02kg	0.01kg	0.02kg	0.005kg	0.01kg	0.02kg	0.01kg	0.02kg	0.005kg	0.01kg	0.02kg	0.01kg	0.02kg	0.001kg	0.002kg	0.005kg	-			-				0.5g	1g	2g	5g	0.5g	1g	2g	2g	5g	10g	-
Linearity		±0.002kg	±0.005kg	±0.005kg	±0.01kg	±0.02kg	±0.05kg	±0.02kg	±0.05kg	±0.01kg	±0.02kg	±0.05kg	±0.02kg	±0.05kg	±0.01kg	±0.02kg	±0.05kg	±0.02kg	±0.05kg	±0.002kg	±0.005kg	±0.01kg	±0.001kg (≤3kg) ±0.002kg (3-6kg) ±0.005kg (>6kg)	±0.005kg (≤15kg) ±0.01kg (15-30kg) ±0.02kg (>30kg)	±0.02kg (≤60kg) ±0.05kg (60-150kg) ±0.1kg (>150kg)	±2g	±10g	±20g	±40g	±1g	±2g	±5g	±10g	±1g	±2g	±4g	±4g	±10g	±20g	-
Stabilization time (approx.)		-								-										0.5s			-			-				0.5s				-						-
Display type and mode		LED display								LCD display										LCD display (with backlight) (g, kg, lb, oz, lb-oz)			Vacuum Fluorescent display (VFD)							LCD display (with backlighting) + Comparator LED indicators x 5 (g, kg, lb, oz, ozt, lb-oz, tl (tael), t (tola), pieces, N)				LCD display						LCD display
Power supply		100-240Vac or optional rechargeable battery SW-OP-02								6 x D (LR 20) batteries										With AC power adapter (included) or optional rechargeable battery HC-02i			With AC power adapter (included)							With 6 x D batteries				With alkaline D batteries or optional AC adapter AX-TB125 / AX-TB126 / AX-TB196 / AX-TB202						With 6x alkaline LR6 batteries or optional AC adapter AX-TB125 / AX-TB126 / AX-TB196 / AX-TB202
Display refresh rate		10 times / s								10 times / s										20 times / s			-							20 times / s				-						-
I/Os	Communication capability	- Optional RS-232C with SW-OP-03 - Optional RS-422 / RS-485 with SW-OP-04								- Optional RS-232C with SCE-03 - Optional USB interface with SCE-02										- Optional RS-232C with FS-03i Optional RS-485 with FS-04i			- Optional RS-232C with HVW-03G - Optional RS-422 / RS-485 with HVW-04WP							-				-						-
I/Os	Outputs	Optional comparator relay output with SW-OP-03								Optional comparator relay output with SCE-03										Optional comparator relay output with FS-03i or FS-04i			Optional comparator relay output with HVW-03G or HVW-04WP							-				-						-

2.2. Platform scales: HV/W-C & HV/W-CP series, FG series

(back to index)

Product series		HV-C series (IP65 with SUS304 stainless steel pan)			HW-C series (IP65 with SUS304 stainless steel pan)				HV-CP series (IP65 with SUS304 stainless steel pan)			HW-CP series (IP65 with SUS304 stainless steel pan)				FG series
Benefits		High-speed measurement—stabilization within 1 second (for the HV-C/CP series) Bright and multi-colored 5-step LED comparator lights Auto-tare and negative comparison functions realizing "take-away" check weighing			High-speed measurement—stabilization within 1 second (for the HV-C/CP series) Bright and multi-colored 5-step LED comparator lights Auto-tare and negative comparison functions realizing "take-away" check weighing				High-speed measurement—stabilization within 1 second (for the HV-C/CP series) Bright and multi-colored 5-step LED comparator lights Auto-tare and negative comparison functions realizing "take-away" check weighing			High-speed measurement—stabilization within 1 second (for the HV-C/CP series) Bright and multi-colored 5-step LED comparator lights Auto-tare and negative comparison functions realizing "take-away" check weighing				High-speed weighing with 1-second stabilization Display unit either on a column (FG-KAM/KAL) or attached directly to the platform (FG-KBM) Washable and hygienic stainless steel weighing pan in two sizes
Pan size		250 x 250mm pan	330 × 424mm pan	390 × 530mm pan	250 × 250mm pan	330 × 424mm pan	390 × 530mm pan		250 x 250mm pan	330 × 424mm pan	390 × 530mm pan	250 × 250mm pan	330 × 424mm pan	390 × 530mm pan		300 x 380mm pan						390 x 530mm pan
Product		HV-15KC	HV-60KC	HV-200KC	HW-10KC	HW-60KC	HW-100KC	HW-200KC	HV-15KCP	HV-60KCP	HV-200KCP	HW-10KCP	HW-60KCP	HW-100KCP	HW-200KCP	FG-30KAM	FG-60KAM	FG-150KAM	FG-30KBM	FG-60KBM	FG-150KBM	FG-60KAL	FG-150KAL
Minimum weighing value		0.001kg (≤3kg) 0.002kg (3-6kg) 0.005kg (>6kg)	0.005kg (≤15kg) 0.01kg (15-30kg) 0.02kg (>30kg)	0.02kg (≤60kg) 0.05kg (60-150kg) 0.1kg (>150kg)	0.002kg	0.01kg	0.02kg	0.04kg	0.001kg (≤3kg) 0.002kg (3-6kg) 0.005kg (>6kg)	0.005kg (≤15kg) 0.01kg (15-30kg) 0.02kg (>30kg)	0.02kg (≤60kg) 0.05kg (60-150kg) 0.1kg (>150kg)	0.002kg	0.01kg	0.02kg	0.04kg	0.002kg	0.005kg	0.01kg	0.002kg	0.005kg	0.01kg	0.005kg	0.01kg
Repeatability (standard deviation)		0.001kg (≤3kg) 0.002kg (3-6kg) 0.005kg (>6kg)	0.005kg (≤15kg) 0.01kg (15-30kg) 0.02kg (>30kg)	0.02kg (≤60kg) 0.05kg (60-150kg) 0.1kg (>150kg)	0.002kg	0.01kg	0.02kg	0.04kg	0.001kg (≤3kg) 0.002kg (3-6kg) 0.005kg (>6kg)	0.005kg (≤15kg) 0.01kg (15-30kg) 0.02kg (>30kg)	0.02kg (≤60kg) 0.05kg (60-150kg) 0.1kg (>150kg)	0.002kg	0.01kg	0.02kg	0.04kg	0.005kg	0.01kg	0.02kg	0.005kg	0.01kg	0.02kg	0.01kg	0.02kg
Linearity		±0.001kg (≤3kg) ±0.002kg (3-6kg) ±0.005kg (>6kg)	±0.005kg (≤15kg) ±0.01kg (15-30kg) ±0.02kg (>30kg)	±0.02kg (≤60kg) ±0.05kg (60-150kg) ±0.1kg (>150kg)	±0.002kg	±0.01kg	±0.02kg	±0.04kg	±0.001kg (≤3kg) ±0.002kg (3-6kg) ±0.005kg (>6kg)	±0.005kg (≤15kg) ±0.01kg (15-30kg) ±0.02kg (>30kg)	±0.02kg (≤60kg) ±0.05kg (60-150kg) ±0.1kg (>150kg)	±0.002kg	±0.01kg	±0.02kg	±0.04kg	±0.01kg	±0.02kg	±0.05kg	±0.01kg	±0.02kg	±0.05kg	±0.02kg	±0.05kg
Stabilization time (approx.)		1s			1.5s				1s			1.5s				1s
Display type and mode		LCD display (with backlight) + 5-step LED comparator signals			LCD display (with backlight) + 5-step LED comparator signals				LCD display (with backlight) + 5-step LED comparator signals			LCD display (with backlight) + 5-step LED comparator signals				LCD display (g, kg, lb)
Power supply		With AC power adapter (included) or 4 x D batteries			With AC power adapter (included) or 4 x D batteries				With AC power adapter (included) or 4 x D batteries			With AC power adapter (included) or 4 x D batteries				With AC power adapter (included) or 4 x C-Batteries
Display refresh rate		10 times / s			10 times / s				10 times / s			10 times / s				10 times / s
I/Os	Communication capability	- Optional RS-232C with HVW-03C - Optional USB interface with HVW-02CB			- Optional RS-232C with HVW-03C - Optional USB interface with HVW-02CB				- Optional RS-232C with HVW-03C - Optional USB interface with HVW-02CB			- Optional RS-232C with HVW-03C - Optional USB interface with HVW-02CB				Optional RS-232C with FG-23 or FG-24
I/Os	Outputs	Optional comparator relay output + buzzer with HVW-04C			Optional comparator relay output + buzzer with HVW-04C				Optional comparator relay output + buzzer with HVW-04C			Optional comparator relay output + buzzer with HVW-04C				Optional comparator output with FG-24

2.3. Counting scales: FC-i/FC-Si series, HC-i series

(back to index)

Product series		FC-Si series		FC-i series							HC-i series
Benefits		Beginner-friendly, Unit Weight Registering Navigator Automatic Counting Accuracy Improvement (ACAI) function Large memory for 500 items		Beginner-friendly, Unit Weight Registering Navigator Automatic Counting Accuracy Improvement (ACAI) function Large memory for 500 items							Beginner-friendly, Unit Weight Registering Navigator Audible Weighing Assist (AWA) beeping function Automatic Counting Accuracy Improvement (ACAI) function
Weighing capacity		0.5kg	5kg	0.5kg	1kg	2kg	5kg	10kg	20kg	50kg	3kg 6lb	6kg 15lb	15kg 30lb	30kg 60lb
Platform size		128 x 128 mm platform	165 x 165 mm platform	205 x 152 mm platform		300 x 280 mm platform					300 x 210 mm platform
Product		FC-500Si	FC-5000Si	FC-500i	FC-1000i	FC-2000i	FC-5000i	FC-10Ki	FC-20Ki	FC-50Ki	HC-3Ki	HC-6Ki	HC-15Ki	HC-30Ki
Minimum weighing value		0.0005g		0.00005g	0.001g	0.002g	0.005g	0.01g	0.02g	0.05g	0.005g or 0.1g	0.01g or 0.2g	0.02g or 0.4g	0.05g or 1g
Repeatability (standard deviation)		0.02g	0.2g	0.05g	0.1g	0.2g	0.5g	1g	2g	5g	0.5g	1g	2g	5g
Linearity		±0.02g	±0.2g	±0.05g	±0.1g	±0.2g	±0.5g	±1g	±2g	±5g	±0.5g	±1g	±2g	±5g
Display type and mode		Vacuum Fluorescent display (VFD) (g, kg, lb)									LCD display
Power supply		100/120/220/240Vac with AC power adapter (included) or optional internal battery FC-02i									With AC power adapter (included) or optional rechargeable battery HC-02i
Display refresh rate		-									10 times / s
I/Os	Communication capability	- Built-in RS-232C - Additional 1-channel (with FC-04i) or 2-channel (with FC-03i)									- Optional RS-232C with HC-03i or HC-04i
I/Os	Outputs	-									- Optional comparator relay output with HC-04i

2.4. Compact scales

(back to index)

Product series		HT-120 series
Benefits		- Unparalleled Battery Life of 500 Hours
Weighing capacity		120g 4.333oz 600ct
Pan size		Ø70mm
Product		HT-120
Minimum weighing value		0.01g 0.001oz 0.05ct
Repeatability (std. deviation)		0.01g
Linearity		±0.01g
Stabilization time (approx.)		-
Display type and mode		LCD display
Power supply		With 4 x AA batteries
